 MOOG 電路旋轉滑動環
|
型 號 |
接點數 |
電流 |
電壓 |
最高轉速 |
內徑 |
型錄下載 |
|
H |
6、12、18、24、36 |
2 amps |
220 VAC |
500 rpm |
無 |
 Download
|
|
AC6373 |
6、12 |
2 amps |
120 VAC/DC |
100 rpm |
無 |
Download |
|
AC6023 |
6、12、18、24 |
2 amps |
210VDC/240VAC |
250 rpm |
無 |
Download |
|
AC6305 |
3動力線及6/9/12訊號線 |
2 amps/5 amps |
120 VAC |
250 rpm |
無 |
Download |
|
AC6310 |
3動力線及3/6訊號線 |
2 amps/10 amps |
120 VAC |
250 rpm |
無 |
Download |
|
AC6355 |
36 - 56 |
2,5,10 amps |
210 VDC |
250 rpm |
無 |
Download |
|
AC7036 |
6,12,18,24(外環)
36,56(內環) |
15 amps(外環)
2,5,10 amps(內環) |
440VAC(外環)
240 VAC(內環) |
250 rpm |
無 |
Download |
|
SRA-73540 |
6、12 |
2 amps |
120 VDC |
250 rpm |
無 |
Download |
|
SRA-73625 |
18 |
2 amps |
120 VDC/VAC |
250 rpm |
無 |
Download |
|
SRA-73526
SRA-73528
SRA-73599 |
6、12、18、24 |
2 amps |
500 VRMS |
250 rpm |
無 |
Download |
|
SRA73574 |
36 |
2 amps |
210 VDC |
600 rpm |
無, |
Download |
|
SRA73587 |
4動力線及24訊號線 |
2 amps/10 amps |
210VDC |
500 rpm |
無 |
Download |
|
AC3757 |
36 |
1 amp |
70 VDC |
4,000 rpm標準
6,000 rpm冷卻 |
無 |
Download |
|
EC3848 |
2 ,6,8,10 |
1 amp |
100 VDC |
10,000 rpm |
無 |
Download |
|
SRA-73683 |
6,12,18,24 |
2 amps |
210VAC |
120 rpm |
0.5” |
Download |
|
AC6200 |
12,24,36,48 |
2 amps |
220 VAC |
250 rpm |
1.5” |
Download |
|
AC6438 |
6,12,18,24 |
5 amps |
250 VAC/DC |
250 rpm |
0.5” |
Download |
|
AC7094 |
30,36,42,48 |
5 amps |
250 VAC/DC |
250 rpm |
0..5" |
Download |
|
AC4598 |
6,12,18,24 |
10 amps |
600 VRMS |
250 rpm |
1.5” |
Download |
|
AC6349 |
6,12,18,24 |
15 amps |
440 VAC |
250 rpm |
1” |
Download |
|
AC6428 |
60,72,84,96 |
2 amps |
220 VAC |
250 rpm |
1- 3/8” |
Download |
|
AC6429 |
48x2amps+6或12x10amps |
2 amps/10 amps |
2 amps：220VAC
10 amps：460VAC |
250 rpm |
1- 3/8” |
Download |
|
AC6231 |
8 |
15 amps |
220 VAC |
2,500 rpm |
1.5” |
Download |
|
AC6275 |
6- 144 |
5,10,30,50 amps |
600 VDC |
1,000 rpm |
2.75” |
Download |
|
AC6098 |
6 - 72 |
10,30,50 amps |
600 VDC |
250 rpm |
4” |
Download |
|
AC6815 |
可客製化 |
2, 3.5, 10 amps |
2 A：60 VAC
3.5 A：110 VAC 10 A：220 VAC |
250 rpm |
1.5” |
Download |
MOOG 光纖旋轉滑動環
|
型號 |
光纖尺寸(Microns) |
Insertion Loss |
Rotation Variation |
Wavelength |
轉速 |
型錄下載 |
|
FO228
(Multimode) |
50/125 or 62.5/125 |
Typical<2.5 dB
Maximun<4.0 dB |
Typical<0.5 dB
Maximun<1.0 dB |
Broadband |
100 rpm |
Download |
|
FO282
(Singlemode) |
9/125 SMF-28 |
Typical<2.5 dB
Maximun<4.0 dB |
Typical<0.5 dB
Maximun<1.0 dB |
Broadband |
100 rpm |
Download |
|
FO197 |
50/125, 62.5/125, 100/140 or 200/230 |
Typical<1.5 dB
Maximun<3.0 dB |
Typical < 0.5 dB
Maximun<1.0 dB |
850, 1300 or 1550nm |
1000rpmm |
Download |
|
|
